Custom Metal Cut Outs
Cookie Cutters For Your Fire Pit
Our metal cut-outs are carved-out with a high pressure water jet cutter, giving them a smooth sleek finish. We can accommodate just about any shape/design; and with our large color library of fireglass we can fulfill just about any design.
Please send along photos of the area you would like to place your custom cut-out as well as detailed measurements and a mock-up of the pattern you'd like to get created. ed@moderustic.com
For More information please give us a call to find out more (909) 989-6129.
Permission / Agreements have been submitted for all exsisitng copyrighted material on this page
NOTE* Duplication of any copyrighted imagery requires permission.
A custom "S" for a fire pit. Fireglass used was Starfire.
A custom "B" for a fire pit.
We layed out some V Blue Reflective fireglass for the customer. Note, the color variance in the fireglass, this shift in color is based on using the camera's flash and not using it. Also the lighting source effects the color of the glass, take a look of the final photo under natural lighting; looks like a different Blue.
This cut-out design was brought to us by Nick Saraniti, whose large fire pit was made a whole lot more interesting after the custom cut out was installed.
Nick bought some V-Blue for the center and used Marigold Yellow Opal and Roma Red for the surrounding flames.
Our cusotmer Jan, came to us with a pattern design that stemed from her beach towel.
Once we get approval from the cardboard mock-up we have the pattern cut with a water jet cutter.
Below a crushed lave base beneath the double Stainless Steel Burner Ring. And a vibrant layer of Azurlite fireglass.
The cut-out is then filled in with 2 seperate Toppings, Pimento Red Opal, Tangerine Orange Opal.
Here are a few pictures of a "J" for Jablonski in Long Beach, California
This was cut from 1/2" stainless steel
Permission to reproduce any copyrighted material is the sole responsibility of the customer. Moderustic Inc. takes no accountability or ownership of any copyrighted materials. Click Here To Find Out More.
The next pictures was of a Bull Dog cut from 1/2" aluminum.
The next two pictures show the whiskers and eye brows inserted.
Below, Teena sent us finished pictures of the Bull Dog LOGO! The glass that is used in the fire pit:
White Sand = Eyes, Teeth
Red Topping = Collar
Amber = Main body
Starfire = Studs on collar
Evergreen and Reflective = All around
Permission to reproduce any copyrighted material is the sole responsibility of the customer. Moderustic Inc. takes no accountability or ownership of any copyrighted materials. Click Here To Find Out More.
Our newest customer is "Google" Here is the CAD drawing they sent us. We fabricated it with 1/2" aluminum. How did they find us you ask? They GOOGLED' us! Of course!
Below is the aluminum frame work that will eventually get covered with firegalss. For the sake presenting the logo properly we poured our crushed lava to enhance the colors. We used a combination of fireglass and Toppings.
The Gray Google logo above is the Cut-Out, which though not used for the fire pit can have further application, if you so wish.
Finished! Now we send it off to be installed in Mountain View California to be installed in front of corporate GOOGLE! The fire pit also will include an electronic ignition as well. We wil provide all pictures after the installation from XL Construction.
Google Corporate Fire Pit.
Crushed Lava
Stratus Blue Topping G126F3
Pumpkin Orange Topping 0312
Crimson G178F3
Emerald Green 1417
Permission to reproduce any copyrighted material is the sole responsibility of the customer. Moderustic Inc. takes no accountability or ownership of any copyrighted materials. Click Here To Find Out More.
Here is another metal design, of our customers initials designed to go into another fire pit. We can create any size or design! With our large selection of Fireglass, Toppers, and Toppings there's no palette we can't accommodate. The customer chose one of our Lipstick Reds for a center accent. The overall size of this "K& U" was 6" wide x 9" tall.
Below we used a Cobalt Blue Topping with a Starfire base glass all around.
We would of hoped for a larger picture from our client - but here is the finished piece.
Permission to reproduce any copyrighted material is the sole responsibility of the customer. Moderustic Inc. takes no accountability or ownership of any copyrighted materials. Click Here To Find Out More.
Here is the Design that was sent to us before we started working on it. We will walk you through the process as explained to us by the client. Now for the construction and pictures...
The following photos were sent to us by our client. A step by step demonstrating how he built his custom fire pit. The metal cut-out comes later. But please follow along as he explains...
I had my local welding fabricator build the base out of ¼” square tube for the circles and 1” square tube for the legs and attached some decorative feet on it. Also attached some L brackets at the top to install the granite top with. I then had my local granite company cut a ¾” thick 52” diameter circle with a 28” opening in the center to accommodate the pan.
Fabricator also built a 28” diameter by 4” deep pan out of 16ga steel. Later we decided to add a ¾” lip around the top edge.
 |
 |
Place base in location, propane line already in place as well as 110v electric with X10 remote socket for LED lights.Install plywood / granite / LED lights onto table base and screw into Tee NutsInstall Pan on top of granite leaving access into the table to complete connections.Disconnect Pilot assembly from AF-4000 MOD and run gas line, ignitor and sensor through hole in pan inside the table
Reconnect Pilot assembly back to AF-4000 MOD ( Be sure to use the correct connections or things will not work
Attach the battery pack to the underside of the granite base in the routed channel to allow the wiring to move in / out for ease of use.
Attach the pilot tube to the AFVK-SP-MH/L module.
Install the burner inside the pan and attach the Gas Outlet connection to the burner.
Attach the Gas Inlet connection to the gas supply line which has a cutoff on it.
Test the remote lighting and check all fittings with soapy water for leaks.
Once everything checked out, install the pan inside the opening.
Install a layer of lava rock under the double burner to lift if from the bottom about 1”
Install ¼” Starfire Glassel on top of lava and covering the burner while leaving the pilot assembly exposed to be able to function.
Tested the remote again to verify operation.
Install the metal logo and fill it with Pimento Red Topping
Install cover Bruce Figura bfigura@swbell.net
